Hertz HCP 4MDK Class D 2000W 4 Channel Marine Mono Amplifier (HCP4MDK)

HCP 4MDK – Ch: 4 – 3 – 2 | 2000 W

New HCP 4MDK features latest generation D-Class 2Ω stable output stage reaching the impressive power RMS of 150 W x 4 with the excellent S/N ratio of 105 dB. Extremely versatile, complete in its functions, provided with Speaker-In and RCA-In inputs to work with any head units, it has been designed to work also in mono (selectable mode), providing the ability to build a two zone stereo or a single zone stereo system with subwoofer.

The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier. HCP 4MDK four channels marine amplifier feature a compact design ready to face the open water environment, providing tons of clean power. The HCP M amplifiers crossover section ensure extreme flexibility: fully adjustable Lo-pass, Hi-pass filters with 12 dB/Oct. slopes and Bass Boost to enhance low frequencies

Highlights

• Output Power (RMS) : 150 W x 4 (4 ohm) / 250 W x 4 (2 ohm)
• Automatic Remote Turn-On/Off with Speaker-In
• Fully adjustable Lo-pass, Hi-pass filters, 12 dB/Oct
• 4-3-2 CH. Configuration providing tons of clean power

Technologies

Hi Power 2 Ohm Stable

Power supply featuring multiple winding transformer, Low-ESR 105°C capacitors, D-Class 2 Ω stable output stage.

Corrosion Protection

Electronics components corrosion caused by exposure in wet environments is totally neutralized by the use of dedicated marinegrade (epoxy coated) PCB boards.

Water Jet Tested

The protection grade IP64 define all the Hertz Marine products as totally protected against water jets of different entities, making them highly performant in the marine environment.

Latest Generation D-Class

Latest generation D-Class 2Ω stable output stage reaching the impressive RMS power of 150 W x 4 with the excellent S/N ratio of 105 dB.

Salt Fog Tested

To satisfy the standards required by ASTM-B117, Hertz Marine products are tested with massive salt fog spray to ensure a complete resistance to corrosion, typical of this atmospheric agent.
