BlackVue LTE Connectivity Module For Dashcams (CM100LTE)
Original price was: $249.00.$96.99Current price is: $96.99.
- 7 days free returns
- Safe Transactions, Happy Customers
- Protecting Your Payment Information
- Quality You Can Count On
External 4G LTE Module
The CM100LTE connects to your compatible BlackVue X Series dashcam to provide easy 4G LTE connectivity. All you need is a valid Nano SIM card. The CM100LTE connects via the USB port of your dashcam. Your BlackVue powers the module and automatically accesses the Cloud when the module is plugged in.
Note: when purchasing, make sure the CM100LTE you choose is compatible with your mobile carrier’s network. Not compatible with DR590X Series.
LTE Connectivity Module
With DR900X and DR750X, you can connect an LTE Connectivity Module (CM100LTE) which is powered by the dashcam and provides 4G LTE connectivity for your dashcam. This allows you to connect your dashcam to BlackVue Cloud and receive notifications to your phone when your parked car gets hit. It also lets you remotely see what your dashcam sees in real time. Being powered by the dashcam, you do not need to worry about the CM100LTE running out of power like you might with a self-powered router.
Pick the right version
The CM100LTE takes Nano SIM cards and comes in multiple variations, which version will work for you depends mostly on the LTE frequency bands supported by your local carrier(s).
| Specifications | |
|---|---|
| LTE Module | CM100LTE [GL] : Quectel EC25-E CM100LTE [NA] : Quectel EC25-A CM100LTE [JP] : Quectel EC25-J CM100LTE [AU] : Quectel EC25-AU |
| LTE Supported Band | EC25-E : B1/B3/B5/B7/B8/B20 EC25-A : B2/B4/B12 EC25-J : B1/B3/B8/B18/B19/B26 EC25-AU : B1/B2/B3/B4/B5/B7/B8/B28 |
| LTE Features | Support up to Non-CA CAT. 4 FDD and TDD LTE-FDD : Max 150Mbps(DL) / Max 50Mbps(UL) LTE-TDD : Max 130Mbps(DL) / Max 30Mbps(UL) |
| Transmitting Power | Class 3 : 23dBm +/-2dBm @ LTE-FDD Bands Class 3 : 24dBm +1/-3dBM @ WCDMA Bands |
| SIM Type | Support Nano SIM Card / 3.0V |
| Connector Type | Micro USB Type-B Connector with Harness Cable |
| USB Interface | Compliant with USB 2.0 specification(Slave Only), Reach up to 480Mbps for data transfer rate |
| Antenna Type | Fixed / Intenna (Main, Diversity) |
| Power Supply | USB Harness Cable : 3.0m Typical Supply Voltage : 5.0V / 1A Supply Input Voltage : 3.3V ~ 5.5V / Max. Current : 2A |
| Power Consumption | Idle Mode : 20mA / Traffic Mode : 570mA @ Max. Power (23dBm) |
| Temperature Range | Operation Temperature Range : -35°C ~ +75°C Storage Temperature Range : -40°C ~ +85°C |
| Certifications | PTCRB, FCC, ISED, RCM, TELEC, WEEE, RoHS |
| Brand | BlackVue |
|---|---|
| Product Parts Warranty | 1 Year Limited |
| Product Labour Warranty | 1 Year Limited |
| Height (in.) | 0.39 |
| Depth (in.) | 2.36 |
| Weight (lbs) | 0.15 |
| Width (in.) | 3.54 |
